Smart LEDbox 25 mm Single Sided

• Ideal for indoor application with 19 mm depth.
• On / off button and power supply provide
   long product life.
• Easy to mount and use.

ACCESORIES

SIZES

20″ X 30″ (508 X 762 mm), 30″ X 40″ (762 X 1016 mm), A1 (594 X 841 mm), A2 (420 X 594 mm), A3 (297 X 420 mm), A4 (210 X 297 mm), B1 (700 X 1000 mm), B2 (500 X 700 mm)

MATERIAL : Silver anodised aluminiumPROFILE: 25 MMWEIGHTPACKING SIZE
ARTICLEEXTERNAL (x-y)POSTERCOPYLIGHTINGWITH PACKING*W X H X D
ULD25TN0A4242 X 329 mm210 X 297 mm190 X 277 mm1700-2000 LUX1,100 kg260 X 420 X 46 mm
ULD25TN0A3329 X 452 mm297 X 420 mm277 X 400 mm3300-3600 LUX1,820 kg350 X 540 X 46 mm
ULD25TN0A2452 X 626 mm420 X 594 mm400 X 574 mm3000-3300 LUX2,960 kg470 X 720 X 46 mm
ULD25TN0A1626 X 873 mm594 X 841 mm574 X 821 mm2700-3000 LUX6,530 kg650 X 960 X 46 mm
ULD25TN0A0873 X 1221 mm841 X 1189 mm821 X 1169 mm2500-2800 LUX10,280 kg890 X 1290 X 46 mm
ULD25TN0B2532 X 732 mm500 X 700 mm480 X 680 mm2900-3200 LUX4,850 kg560 X 820 X 46 mm
ULD25TN0B1732 X 1032 mm700 X 1000 mm680 X 980 mm2500-2800 LUX8,710 kg780 X 1100 X 46 mm
ULD25TN023540 X 794 mm508 X 762 mm488 X 742 mm2900-3200 LUX5,130 kg570 X 870 X 46 mm
ULD25TN034794 X 1048 mm762 X 1016 mm742 X 996 mm2500-2800 LUX9,250 kg820 X 1120 X 46 mm

* W:Width H: Height D: Depth

Description

Smart LEDbox 25 mm Single Sided



Lightbox signs are high-end and attractive custom signage solutions for a wide range of indoor applications: retail point-of-purchase, tradeshow displays, movie theatres, sports facilities, shopping malls, casinos, and more.



These light boxes are only 19 mm in depth. They are one of the thinnest lightboxes in the market. They would make great choices for high-traffic areas, especially because they do not obstruct walking paths.

Translucent poster material should be used for printing the signage of these edge lit displays. When illuminated, your advertisement will surely attract lots of attention, thanks to this LED edge lit lightbox. You do not need to worry if you want to use it for a long time, because LED bulbs last very long. You cannot see the LED bulbs from outside, since the LED bulbs of the indoor light box are embedded in the sides of the frame.

High illumination is achieved by specially treated acrylic and provides homogenous illumination. The built-in on /off switch and outer power supply helps long product life. They consume less energy since their LED lighting is lower voltage compared to other signage display frames in the market. Through this LED lighting saves up to 60% energy costs. Besides they are less expensive as well. This results in cost saving both initially and after overall usage.

Light box poster frames, are easy to load and re-load thanks to their snap open framing. You simply snap up all four sides of the frame and easily insert your poster or take out. Each frame includes an acrylic non-glare PET lens to diffuse light across your graphics. It gives an impressive effect to grab the passers-by. They are designed for wall mounting and come with the necessary hardware for mounting. Also, each product has two wall hangers to move hangers in portrait and landscape position.

If you wish to use your LED frame 24 hours in 7 days, please ask for special 7/24 power supplies.

Smart Ledbox 25 mm Single Sided

Smart Ledbox 25 mm Single Sided

Smart Ledbox 25 mm Single Sided
